OIL SYSTEM RADIATOR

Go to Split View

OIL SYSTEM RADIATOR

Location Part # Quantity* Description Price Add To Cart
1 400117098A 1 BRACKET Unavailable
2 N0902322 1 SCREW M6X10 Unavailable
3 N90847901 4 SCREW Unavailable
4 7L117413A 1 HOSE Unavailable
5 7L115687B 1 HOSE Unavailable
6 N10451402 4 SCREW M6X16 Unavailable
7 N90265703 2 NUT M6X7.6 Unavailable
8 400115339A 1 HEAT SHIELD Unavailable
9 400115707 1 CONNECTOR Unavailable
10 7L115664C 1 LH PIPE Unavailable
11 N10233401 2 CLAMP 16.2 X 7 X 0.60 Unavailable
13 7L115311D 1 PLUG Unavailable
14 0 PIPE (VALID FOR A DIFFERENT MARKET/MODEL YEAR) Unavailable
16 N90107203 2 CLAMP 12 X 8.0 X 0.5 Unavailable
17 357711798 2 RUBBER SEAL Unavailable
18 N10005104 2 SCREW M8X35 Unavailable
19 7L115373A 1 OIL TANK Unavailable
20 400115341B 1 HEAT SHIELD Unavailable
21 N10156305 6 SCREW M6X12 Unavailable
22 7L115333B 1 RUBBER BUFFER Unavailable
23 N0138486 1 WASHER A16X22 Superseded
24 N0160282 1 OIL DRAINAGE M16X1-5 Superseded
25 7L919501A 1 TEMPERATURE SENSOR Unavailable
26 7L115659E 1 OIL SUCTION ROSE Unavailable
27 7L115689 1 PIPE Unavailable
28 N91107101 1 WASHER Unavailable
29 7L115688 1 PIPE Unavailable
30 400117335 1 COOLER EXIT CONE Unavailable
31 418864929 1 PROTECTION Unavailable
32 400117097A 1 BRACKET Unavailable
33 400317025 1 LH CONVEYOR Unavailable
34 7L117015B 1 OIL COOLER Unavailable
35 7L133741 1 SUPPORT Unavailable
36 7L115255 1 FLANGE Unavailable
37 WHT000759 2 STUD BOLT (M6X14) Unavailable
38 N10129201 1 O-RING 34.5X2.65 Unavailable
39 1J0711795 2 SPACER Unavailable
40 400422095 1 FAIRLEAD Unavailable
41 7L115333 1 RUBBER BUFFER Unavailable
42 N90937701 1 CLAMP Unavailable

* Quantity shown indicates the number of pieces used in the diagram.
