ELECTRICAL SYSTEM

Go to Split View

ELECTRICAL SYSTEM

in cart
Go to Split View
Location Part # *Qty Description Price Add To Cart
Location: 1 Prev | Next Part: N10017302 *Qty: 5 NUT M5 $0.90
Location: 2 Prev | Next Part: 8H0959433L *Qty: 1 COMFORT CONTROL UNIT (315 MHZ REMOTE CONTROL WITHOUT PANIC BUTTON) $466.54
Location: 3 Prev | Next Part: N10049308 *Qty: 4 SCREW M8X20.00 $1.00
Location: 4 Prev | Next Part: 401907285 *Qty: 1 BRACKET $60.85
Location: 7 Prev | Next Part: 400941645A *Qty: 1 BRACKET $46.33
Location: 8 Prev | Next Part: 400971107 *Qty: 1 WIRING HARNESS $116.84
Location: 9 Prev | Next Part: 400907279 *Qty: 1 ILM CONTROL UNIT $565.36
Location: 10 Prev | Next Part: N0150825 *Qty: 5 NUT M6 $0.90
Location: 11 Prev | Next Part: 400959497 *Qty: 1 BRACKET $30.88
Location: 12 Prev | Next Part: 400959433A *Qty: 1 GFA CONTROL UNIT (SUPPLY VIN ? TO BE PROGRAMMED) $2,242.74
Location: 13 Prev | Next Part: N90847901 *Qty: 3 SCREW M6X15.0 $0.90
Location: 14 Prev | Next Part: 400972895 *Qty: 3 SPACER $21.10
Location: 15 Prev | Next Part: 400972081 *Qty: 3 PUFFER $8.40
Location: 16 Prev | Next Part: 408959655 *Qty: 1 AIRBAG CONTROL UNIT + SENSOR $588.34
Location: 17 Prev | Next Part: N0902423 *Qty: 3 SCREW M6X18.00 $0.90
Location: 18 Prev | Next Part: N10082911 *Qty: 2 SCREW M6X16.00 $0.90
Location: 19 Prev | Next Part: 400807777 *Qty: 1 BRACKET $13.48
Location: 20 Prev | Next Part: 8E0909511A *Qty: 1 BOX DOOR CONTROL E.C.U. (USA VERSION) $1,030.97
Location: 21 Prev | Next Part: 410971946 *Qty: 1 CONNECTOR $34.46
Location: 22 Prev | Next Part: *Qty: 0 REAR VIEW CAMERA CONTROL UNIT (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 23 Prev | Next Part: *Qty: 0 SCREW (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 24 Prev | Next Part: 400971532 *Qty: 1 BRACKET $27.03
Location: 25 Prev | Next Part: 400971532 *Qty: 1 BRACKET $27.03
Location: 26 Prev | Next Part: N0150825 *Qty: 4 NUT M6 $0.90
Location: 27 Prev | Next Part: *Qty: 1 BRACKET (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 28 Prev | Next Part: *Qty: 2 SCREW M6X15.0 (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 28 Prev | Next Part: *Qty: 0 0 Call
Location: 29 Prev | Next Part: *Qty: 1 SCREW M6X15 (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 30 Prev | Next Part: *Qty: 0 CLAMP (VALID FOR A DIFFERENT MODEL) Call
Location: 31 Prev | Next Part: *Qty: 1 BRACKET (VALID FOR A DIFFERENT MODEL) Call
Location: 32 Prev | Next Part: *Qty: 1 CELLULAR PHONE (VALID FOR A DIFFERENT MODEL) Call
Location: 33 Prev | Next Part: *Qty: 1 BRACKET (VALID FOR A DIFFERENT MODEL) Call
Location: 34 Prev | Next Part: *Qty: 0 BRACKET (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 36 Prev | Next Part: *Qty: 0 WIRING HARNESS BOX DOOR CONTROL E.C.U. (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 37 Prev | Next Part: *Qty: 0 ETB CONTROL UNIT (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 38 Prev | Next Part: *Qty: 0 NUT M6 (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 39 Prev | Next Part: *Qty: 0 BRACKET (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 40 Prev | Next Part: *Qty: 0 NUT M6 (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 41 Prev | Next Part: *Qty: 0 SCREW M6X16 (VALID FOR A DIFFERENT MODEL YEAR) Call
Location: 45 Prev | Next Part: *Qty: 1 ADHESIVE SPONGE RUBBER (VALID FOR A DIFFERENT MODEL) Call
Location: 46 Prev | Next Part: *Qty: 1 ADHESIVE SPONGE RUBBER (VALID FOR A DIFFERENT MODEL) Call

* Quantity shown indicates the number of pieces used in the diagram.
