CLUTCH CONTROLS (STARTING FROM CAR NO. 80095 - 80146 CH - 80177 US)

Go to Split View

CLUTCH CONTROLS (STARTING FROM CAR NO. 80095 - 80146 CH - 80177 US)

in cart
Location Part # *Qty Description Price Add To Cart
Location: - Prev | Next Part: 135076 *Qty: 1 0 9 1/2" double disc clutch complete Call
Location: 1 Prev | Next Part: 124098 *Qty: 1 Pressure plate Superseded
Location: 2 Prev | Next Part: 135077 *Qty: 1 Clutch disc with spring drive Call
Location: 3 Prev | Next Part: 135078 *Qty: 1 Clutch disc without spring drive $369.92
Location: 4 Prev | Next Part: 110019 *Qty: 6 Stud
Until engine no. 20207
$35.49
Location: 4 Prev | Next Part: 143590 *Qty: 6 Stud
Starting engine no. 20208
$56.37
Location: 5 Prev | Next Part: 16100821 *Qty: 6 Nut $3.57
Location: 6 Prev | Next Part: 10516670 *Qty: 6 Washer $0.90
Location: 7 Prev | Next Part: 136007 *Qty: 1 Spacer ring $464.55
Location: 8 Prev | Next Part: 124101 *Qty: 1 Intermediate ring Call
Location: 9 Prev | Next Part: 124103 *Qty: 3 Stud Call
Location: 10 Prev | Next Part: 104756 *Qty: 3 Sealing ring $9.73
Location: 11 Prev | Next Part: 109466 *Qty: 6 Spacer Call
Location: 12 Prev | Next Part: 138383 *Qty: 1 Clutch shaft Call
Location: 13 Prev | Next Part: 109342 *Qty: 1 Shoulder washer $1.10
Location: 14 Prev | Next Part: 103042 *Qty: 1 Bearing $249.85
Location: 15 Prev | Next Part: 70000567 *Qty: 1 Thrust Bearing
Use on Exhaustion of 126608
Call
Location: 15 Prev | Next Part: 141700 *Qty: 1 Thrust bearing Superseded
Location: 16 Prev | Next Part: 138375 *Qty: 1 Thrust bearing supporting bush $656.17
Location: 17 Prev | Next Part: 138374 *Qty: 1 Bush supporting flange $1,676.96
Location: 18 Prev | Next Part: 138377 *Qty: 1 Plate $138.68
Location: 19 Prev | Next Part: 10977521 *Qty: 2 Screw $0.90
Location: 20 Prev | Next Part: 106849 *Qty: 2 Washer Superseded
Location: 21 Prev | Next Part: 139440 *Qty: 1 Sealing ring $111.58
Location: 22 Prev | Next Part: 139439 *Qty: 1 Sealing ring $41.81
Location: 23 Prev | Next Part: 10267550 *Qty: 2 Plug Superseded
Location: 24 Prev | Next Part: 121813 *Qty: 2 Sealing ring Superseded
Location: 25 Prev | Next Part: 121814 *Qty: 1 Sealing ring $10.53
Location: 26 Prev | Next Part: 138680 *Qty: 1 Sealing ring $47.20
Location: 27 Prev | Next Part: 121717 *Qty: 2 Preloading spring $16.68
Location: 28 Prev | Next Part: 138388 *Qty: 1 Sealing ring $19.59
Location: 29 Prev | Next Part: 121699 *Qty: 1 Bleeder screw $3.07
Location: 30 Prev | Next Part: 124841 *Qty: 1 Pipe from master cylinder to flexible $47.98
Location: 31 Prev | Next Part: 10440990 *Qty: 2 Pipe supporting backet $1.96
Location: 32 Prev | Next Part: 109789 *Qty: 1 Extension for breather $28.94
Location: 33 Prev | Next Part: 13411990 *Qty: 1 Brather $4.38
Location: 34 Prev | Next Part: 124840 *Qty: 1 Flexible hose for cluthc hydraulic control Call
Location: 35 Prev | Next Part: 110810 *Qty: 1 Pipe securing plate $1.60
Location: 36 Prev | Next Part: 142990 *Qty: 1 Clutch housing complete $2,078.47
Location: 36 Prev | Next Part: 138192 *Qty: 1 Clutch housing
With assembly no. 142990
Superseded
Location: 37 Prev | Next Part: 13544621 *Qty: 1 Stud $1.20
Location: 38 Prev | Next Part: 13544521 *Qty: 2 Stud Superseded
Location: 39 Prev | Next Part: 13544021 *Qty: 6 Stud $1.65
Location: 40 Prev | Next Part: 13544221 *Qty: 1 Stud Superseded
Location: 41 Prev | Next Part: 102704 *Qty: 2 Dowel $19.74
Location: 42 Prev | Next Part: 13516621 *Qty: 4 Stud $0.90
Location: 43 Prev | Next Part: 106852 *Qty: 4 Washer Superseded
Location: 44 Prev | Next Part: 16100821 *Qty: 4 Nut $3.57
Location: 45 Prev | Next Part: 104280 *Qty: 1 Oil drain plug $10.09
Location: 46 Prev | Next Part: 10263460 *Qty: 1 Gasket Superseded
Location: 47 Prev | Next Part: 126496 *Qty: 2 Union Superseded
Location: 48 Prev | Next Part: 10257060 *Qty: 2 Gasket $0.90
Location: 49 Prev | Next Part: 14326150 *Qty: 1 Plug $0.90
Location: 50 Prev | Next Part: 104747 *Qty: 1 Sealing ring $1.53
Location: 51 Prev | Next Part: 136009 *Qty: 3 Centuring dowel $54.89
Location: 52 Prev | Next Part: 14163670 *Qty: 1 Pin $0.93

* Quantity shown indicates the number of pieces used in the diagram.
